50-65 HP
Heavy Duty 4-in-1 Bucket For Skid Steers
Dig, load, grade, and grapple with a stronger build designed for mid-sized skid steers. The Skid Steer Heavy Duty 4-in-1 Bucket is rated for 50–65 HP machines and comes equipped with dual 2.5″ x 8″ hydraulic cylinders for powerful clamping and control. A thicker 3/4″ x 6″ cutting edge provides added durability.
Key Features:
- Available widths: 60″, 63″, 66″, 72″, 78″, and 84″
- Rated for skid steers in the 50–65 HP range
- Optional welded teeth for digging (not compatible with bolt-on edge)
- Optional bolt-on front cutting edge for extended wear
| 60" Heavy Duty 4 in 1 Bucket | 63" Heavy Duty 4 in 1 Bucket | 66" Heavy Duty 4 in 1 Bucket | 72" Heavy Duty 4 in 1 Bucket | 78" Heavy Duty 4 in 1 Bucket | 84" Heavy Duty 4 in 1 Bucket | |
|---|---|---|---|---|---|---|
| SKU | HD4N1-60 | HD4N1-63 | HD4N1-66 | HD4N1-72 | HD4N1-78 | HD4N1-84 |
| Weight (Lbs.) | 748 | 785 | 810 | 840 | 910 | 980 |
| Width (") | 60 | 63 | 66 | 72 | 78 | 84 |
| Height (") | 28 | 28 | 28 | 28 | 28 | 28 |
| Depth (") | 30" Closed | 30" Closed | 30" Closed | 30" Closed | 30" Closed | 30" Closed |
| Rated for (HP) | 50-65 HP | 50-65 HP | 50-65 HP | 50-65 HP | 50-65 HP | 50-65 HP |
| Cutting Edge | 3/4" x 6" | 3/4" x 6" | 3/4" x 6" | 3/4" x 6" | 3/4" x 6" | 3/4" x 6" |
| Cylinder Size | 2.5" x 8" | 2.5" x 8" | 2.5" x 8" | 2.5" x 8" | 2.5" x 8" | 2.5" x 8" |
| Bucket Wrap | 1/4" | 1/4" | 1/4" | 1/4" | 1/4" | 1/4" |
| Side Cutters | Optional | Optional | Optional | Optional | Optional | Optional |
| Welded Teeth | Optional | Optional | Optional | Optional | Optional | Optional |
| Bolt-On Front Cutting Edge | Optional (Not Configurable with Welded Teeth) | Optional (Not Configurable with Welded Teeth) | Optional (Not Configurable with Welded Teeth) | Optional (Not Configurable with Welded Teeth) | Optional (Not Configurable with Welded Teeth) | Optional (Not Configurable with Welded Teeth) |
| Bucket Capacity (ft³) | 12.79 | 13.42 | 14.66 | |||
| Bucket Capacity (yd³) | 0.47 | 0.5 | 0.54 |
