65+ HP
Skid Steer X-Treme Long Bottom Bucket For Skid Steers
Take on demanding grading, digging, and hauling with a bucket built for extreme performance. The X-Treme Long Bottom Bucket offers a variety of widths, featuring a heavy-duty 1″ × 8″ cutting edge and a reinforced 1/4″ bucket wrap for maximum durability. Its low-profile design improves visibility. This bucket is engineered for operators who need strength and efficiency in every pass.
Key Features:
- Width: 60″ to 96″
- Rated for: 65+ HP machines
- Optional options: teeth, side cutting teeth, or bolt-on edge
Swipe to compare models →
| 60" X-Treme Long Bottom Bucket | 63" X-Treme Long Bottom Bucket | 66" X-Treme Long Bottom Bucket | 72" X-Treme Long Bottom Bucket | 74" X-Treme Long Bottom Bucket | 78" X-Treme Long Bottom Bucket | 81" X-Treme Long Bottom Bucket | 84" X-Treme Long Bottom Bucket | 90" X-Treme Long Bottom Bucket | 96" X-Treme Long Bottom Bucket | |
|---|---|---|---|---|---|---|---|---|---|---|
| SKU | Standard: (LBB60) With Teeth: (LBB60T) | Standard: (LBB63) With Teeth: (LBB63T) | Standard: (LBB66) With Teeth: (LBB66T) | Standard: (LBB72) With Teeth: (LBB72T) | Standard: (LBB74) With Teeth: (LBB74T) | Standard: (LBB78) With Teeth: (LBB78T) | Standard: (LBB81) With Teeth: (LBB81T) | Standard: (LBB84) With Teeth: (LBB84T) | Standard: (LBB90) With Teeth: (LBB90T) | Standard: (LBB96) With Teeth: (LBB96T) |
| Weight (Lbs.) | Array | 414-? | 432-487 | 454-512 | 468-? | 498-? | 500-542 | 516-577 | 558-621 | 595-658 |
| Width (") | 60 | 63 | 66 | 72 | 74 | 78 | 81 | 84 | 90 | 96 |
| Height (") | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 |
| Length (") | 35" | 35" | 35" | 35" | 35" | 35" | 35" | 35" | 35" | 35" |
| Rated for (HP) | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines | 65+ Machines |
| Cutting Edge | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" | 1" x 8" |
| Bucket Wrap (") | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" |
| Wear Bars & Side Edge (") | 3/8 | 3/8 | 3/8 | 3/8 | 3/8 | 3/8 | 3/8 | 3/8 | 3/8 | 3/8 |
| Optional Teeth Available | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Optional Side Cutting Teeth Available | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Optional Bolt on Edge Available | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Bucket Capacity (ft³) | 14.72 | 15.44 | 16.87 | 18.3 | 19.02 | 19.74 | 21.17 | 22.6 | ||
| Bucket Capacity (yd³) | 0.55 | 0.57 | 0.62 | 0.68 | 0.7 | 0.73 | 0.78 | 0.84 |
